Chapter 3
B150M-P73 USER MANUAL
52
CPU OverClocking Configuration
Scroll to this item to view the following screen:
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking
Configuration
Tweak
CPU OverClocking Configuration
Memory Configuration
Profile Configuration
Main Advanced Chipset Tweak Security Boot Exit
Turbo Mode.
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
Tweak Menu
Intel(R) Core(TM) i5-6600K CPU @ 3.50GHz
Processor Speed 3600 MHz
Memory Frequency 1600 MHz
Total Memory 4096 MB
Turbo Mode Enabled
Package Power Limit MSR Lock Disabled
Power Limit 1 Override Disabled
Power Limit 1 0
Power Limit 1 Window 0
Power Limit 2 Override Enabled
Power Limit 2 0
Realtime CPU Ratio 20
Performance Mode Boost
TDP Lock Disabled
1-Core Ratio Limit Override 0
2-Core Ratio Limit Override 0
3-Core Ratio Limit Override 0
4-Core Ratio Limit Override 0
Package Power Limit MSR Lock (Disabled)
Use this item to enable or disable locking of Package Power Limit settings. When
enabled, PACKAGE_POWER_LIMIT MSR will be locked and a reset will be required to
unlock the register.
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
