Chapter 3
B150M-P73 USER MANUAL
39
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (AHCI)
Use this item to select SATA mode.
Determines how SATA
controller(s) operate.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
SATA Configuration
SATA Mode AHCI
SATA Port1
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port2
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port3
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port4
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port5
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port6
Not Present
Spin Up Device Disabled
External SATA Disabled
Press <Esc> to return to the Advanced Menu page.
SATA Port 1~6 (Not Present)
This motherboard supports six SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
Spin up Device (Disabled)
On an edge detect from 0 to 1, the PCH starts a COMRESET initialization sequence
to the device.
External SATA (Disabled)
Use this item to enable or disable External SATA Support.
