Chapter 3
B150M-P73 USER MANUAL
43
Trusted Computing
Use this item to show the information of trusted computing configuration.
Enables or Disables BIOS
support for security device.
O.S. will not show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
TPM Support (Enabled)
Use this item to enable or disable the TPM support. O.S. will not show TPM. Reset
of platform is required.
Platform Hierarchy (Enabled)
Use this item to enable or disable the platform hierarchy.
Pending operation (None)
Schedule an Operation for the Security Device. NOTE: Your Computer will reboot
during restart in order to change State of Security Device.
TPM20 Device Found
TPM Support Enabled
Pending operation None
Platform Hierarchy Enabled
Storage Hierarchy Enabled
Endorsement Hierarchy Enabled
HashPolicy Sha-1
TPM 20 InterfaceType CRB
Device Select Auto
Storage Hierarchy (Enabled)
Use this item to enable or disable the storage hierarchy.
Endorsement Hierarchy (Enabled)
Use this item to enable or disable the Endorsement hierarchy.
HashPolicy (Sha-1)
Use this item to select the Hash policy to use. SHA-2 is most secure but might not
be supported by all operating systems.
TPM 20 InterfaceType (CRB)
Use this item to select the communication interface to TPM 20 device.
Device Select (Auto)
TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to
TPM 2.0 devices, Auto will support both with default set to TPM 2.0 devices if not
found, TPM 1.2 devices will be enumerated.
Press <Esc> to return to the Advanced Menu page.
