3
Z87H3-A3X
USER MANUAL
Chapter 1
• AMI BIOS with 64Mb SPI Flash ROM
• Supports Plug and Play, STR (S3)/ STD(S4), Hardware Monitor
• Audio, LAN, can be disabled in BIOS
• F7 hot key for boot up devices option
• Supports ACPI & DMI
• Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only)
• Supports Dual/Triple Dispaly
• Supports Over-Clocking
• Supports GUI UEFI BIOS II
• Supports Multi-Language
• Supports AC’97/HD Audio auto detect (default)
System BIOS
• ATX Size, 305mm x 220mmForm Factor
• ECS Exclusive AP: Supports eBLU*
1
/eDLU/eOC*
1
/eSF*
1
/EZ
Charger*
1
• 3rd Party Bundled software: Cyberlink*
2
/Norton*
2
/Muzee*
2
/
Sound Blaster Cinema*
2
/MAGIX*
2
AP/Bundled
Software
Support
Note:
*
1
Microsoft .NET Framework 3.5 is required.
*
2
Free bundle software including ECS DVD: Cyberlink/Norton/
Muzee/Sound Blaster Cinema/MAGIX.
• 6 x SATA 6Gb/s connectors*
• 1 x SPDIF out header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x COM header
• 1 x CLR_CMOS jumper
• 1 x Parallel port header (LPT)
• 1 x Trusted platform module header (TPM)
• 1 x Speaker header
• 1 x Case open header
Note: *The gray SATA3_6 connector will become unavailable when
eSATA connector is used.
