Chapter 3

A55F-M4 USER MANUAL

The Advanced menu items allow you to change the settings for the CPU and other

system.

Advanced Menu

LAN Configuration Parameters

Main Advanced Chipset M.I.B III Boot Security Exit

+/- : Change Opt.

Enter/Dbl Click : Select





: Select Screen

/Click: Select Item

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit

LAN Configuration

PC Health Status

Power Management Setup

ACPI Settings

CPU Configuration

SATA Configuration

USB Configuration

Super IO Configuration

Intel(R) Smart Connect Technology
