Chapter 1
2
A55F-M4 USER MANUAL
CPU
Specifications
• AMD A55 ChipsetChipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 UDIMM sockets support up to 16 GB
• Supports DDR3
1866*/1600/1333 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot
• 1 x PCI Express x1 Gen2 slot
• 1 x PCI slot
• Supported by AMD A55 (Hudson D2)
- 4 x Serial ATA 3Gb/s devices
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-Sub port (VGA)
• 1 x HDMI port (optional)
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, Line out, Mic_in Rear)
Rear Panel I/O
LAN
• Realtek RTL8111E-VL-CG Giga Lan
• Socket FM1 for AMD A series processors
• Supports CPU up to 100W TDP
Note: Please go to ECS website for the latest CPU support list.
Note: *Due to the limitation of chipset spec, it supports up to
1866 MHz for motherboard with a single DIMM per channel.
Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x SPDIF out header
• 1 x Front panel USB power select jumper
• 1 x Rear USB/PS2 power select jumper
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x Parallel port header(LPT)
• 1 x CLR_CMOS header
Internal I/O
Connectors &
Headers
• VT1705CE 6-Ch High Definition audio CODEC
- 6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
