Chapter 3
A55F-M4 USER MANUAL
36
Max Speed (2300 MHz)
This item shows the maximum speed of the CPU.
Microcode Patch Level (3000025)
This item shows the Microcode revision.
L1 Instruction Cache (64KB/2-way)
This item shows CPU L1 Instruction Cache.
L1 Data Cache (64KB/2-way)
This item shows CPU L1 Data Cache.
L2 Cache (512KB/16-way)
This item shows CPU L2 Cache.
No L3 Cache Present
This item shows CPU L3 Cache.
C6Mode (Enabled)
This item enables or disables the C6 mode.
CPB Mode (Auto)
This item is used to set the CPB mode.
AMD C&Q (Enabled)
This item enables or disables the CPU C&Q Function.
SB Spread Spectrum (Enabled)
This item enables or disables the SB Clock Spread Spectrum.
Press <Esc> to return to the Advanced Menu page.
CPU Configuration
The item in the menu shows the CPU.
Main Advanced Chipset M.I.B III Boot Security Exit
Enter/Dbl Click : Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
/Click: Select Item
: Select Screen
CPU Configuration
Node0: AMD Engineering Sample
Max Speed: 2300 MHZ
Microcode Patch Level: 3000025
--------- Cache per Core ---------
L1 Instruction Cache: 64 KB/2-way
L1 Data Cache: 64KB/2-way
L2 Cache: 512KB/16-way
No L3 Cache Present
C6 Mode Enabled
CPB Mode Auto
AMD C&Q Enabled
SB Spread Spectrum Enabled
Enable/disable C6
