A55F-M4 USER MANUAL

Chapter 4

eBLU

ECS eBLU utility makes BIOS update faster and easier. eBLU will list the latest BIOS

with a default check-mark. Click”install” button to install.

eDLU

ECS eDLU utility makes updating drivers fast and easy. eDLU saves time and hassle

by listing all the latest drivers online. Just select the one you prefer and start to

download and install the drivers.

eSF

eSF(Smart Fan) utility provides easy and safe way to adjust fan speed in accordance

with your PC’s system loading and temperature.

It has five modes to adjust fan speed in a safe range without entering the BIOS to

optimize your system cooling environment.

Microsoft .NET Framework 3.5 is required.
