52 53
English
Z170A-X1
OREF_RI
Congure OREF_RI.
tREFIx9
Congure tREFIx9.
txSDLL
Congure txSDLL.
txs_oset
Congure txs_oset.
tZQOPER
Congure tZQOPER.
tMOD
Congure tMOD.
ZQCS_period
Congure ZQCS_period.
tZQCS
Congure tZQCS.
Advanced Setting
ODT WR (CH A)
Congure the memory on die termination resistors' WR for channel A.
ODT WR (CH B)
Congure the memory on die termination resistors' WR for channel B.
ODT PARK (CH A)
Congure the memory on die termination resistors' PARK for channel A.
ODT PARK (CH B)
Congure the memory on die termination resistors' PARK for channel B.
ODT NOM (CH A)
Use this to change ODT (CH A) Auto/Manual settings. e default is [Auto].
