ASRock deskmini 110 [25/70] English
![ASRock deskmini 110 [25/70] English](/views2/1213329/page25/bg19.png)
20 21
English
4. Place another HDD/SSD on the tray B shown in Step 1.
en turn the motherboard tray upside down and secure the HDD/SSD with the four
screws.
*Removing the motherboard before installing the second HDD/SSD.
5. Connect the SATA Data and Power Cable to the HDD/SSD.
6. Connect the other end of the SATA Cables to the SATA Connectors on the motherboard.
