ASRock deskmini 110 [26/70] Complete
![ASRock deskmini 110 [26/70] Complete](/views2/1213329/page26/bg1a.png)
20 21
English
DeskMini series
3.8 Complete
1. Connect the power button cable to the System Panel Header on the motherboard.
2. Align the motherboard tray with the two sliding tracks on the chassis while sliding it
back to the chassis.
3. en refasten the four screws that you removed earlier.
PANEL1
Sliding Track
