ASRock deskmini 110 [56/70] Deep sleep
![ASRock deskmini 110 [56/70] Deep sleep](/views2/1213329/page56/bg38.png)
50 51
English
DeskMini series
PCH DMI ASPM Support
is option enables/disables the ASPM support for all PCH DMI devices.
IOAPIC 24-119 Entries
Enable or disable IOAPIC 24-119 Entries to expand your PIROI-PIROX.
Share Memory
Congure the size of memory that is allocated to the integrated graphics processor when
the system boots up.
Onboard LAN
Enable or disable the onboard network interface controller.
Onboard HD Audio
Enable/disable onboard HD audio. Set to Auto to enable onboard HD audio and
automatically disable it when a sound card is installed.
Onboard HDMI HD Audio
Enable audio for the onboard digital outputs.
WAN Radio
Enable/disable the WiFi module's connectivity.
Deep Sleep
Congure deep sleep mode for power saving when the computer is shut down.
Restore on AC/Power Loss
Select the power state aer a power failure. If [Power O] is selected, the power will
remain o when the power recovers. If [Power On] is selected, the system will start
to boot up when the power recovers.
Good Night LED
By enabling Good Night LED, the Power/HDD LEDs will be switched o when the
system is on. It will also automatically switch o the Power and Keyboard LEDs
when the system enters into Standby/Hibernation mode.
