xiv
* Specifications are subject to change without notice.
Z10PA-U8 Series specifications summary
Model Name
Z10PA-U8/10G-2S Z10PA-U8
Storage
SAS Controller
Optional kits:
ASUS PIKE II 3008 8-port SAS 12G RAID card
ASUS PIKE II 3108 8-port SAS 12G HW RAID card
Graphic
VGA
Aspeed AST2400 32 MB
Onboard I/O
Connectors
TPM Header
1
PSU Connector
24-pin SSI power connector + 8-pin SSI 12V
Management
connector
Onboard socket for optional management card
USB Connectors
1 x USB 3.0 pin header (up to 2 devices)
1 x USB 2.0 pin header (up to 2 devices)
1 x USB 2.0 connector (Type A USB socket)
Fan Header
6 x 4-pin
SMBus
1
Chassis Intruder
1
Front LAN LED
2
Serial Port Header
1
M.2 Connector
1 (NGFF Type 2242, Capacity 16 ~ 128 GB)
Rear I/O
Connectors
VGA Port
1
External USB Port
2 x USB 3.0
2 x USB 2.0
SFP+
2 x SFP+ —
RJ-45
2 x GbE LAN
1 x Management LAN
PS/2 KB/Mouse
1
Management
Solution
Software
ASWM Enterprise
Out of Band
Remote
Management
Optional ASMB8-iKVM for KVM-over-Internet
Monitoring
CPU Temperature
FAN RPM
Environment
Operation temperature:
10°C ~ 35°C
Non operation temperature:
-40°C ~ 70°C
Non operation humidity:
20% ~ 90% (Non condensing)
