Ronin-M
User Manual
6
©
2015 DJI. All Rights Reserved.
Charger ×1
Automatic switching charger 110-240V
DJI Intelligent Battery ×2
Power source for the gimbal.
Supplies power for other external devices.
Cable Pack ×1
ANSI cable
JIS or CE cable (varies by region)
Micro-USB Cable×1
For rmware upgrades.
Camera Mounting Plate ×1
For mounting your camera onto the gimbal.
Accessories Package
Camera Screw A (1/4'')×2
Camera Screw B (3/8'') ×2
Camera Screw C (1/4'')×2
Camera Screw D (3/8'') ×2
Lens Support ×1
Lens Support Screw ×1
Allen Wrench ×2 (3 mm & 3/16”)
