Ronin-M

User Manual

Using the DJI Intelligent Battery

[1] Battery Level Indicators

[2] Power Button (with LED indicator)

[3] Thumb Screws

Getting Started

[

]

[

]

[

]

High

Low

Battery Level

3. The upper half of the tuning stand can be removed by loosening the rear knob. You can mount it on

any C-stand stud that ts into the mounting hole. When mounting this part to a C-stand, check the

balance of the stand so that it will not tip over. When placing the C-stand on a table, ensure the table

is at and level.

Checking the battery level: When the DJI Intelligent Battery is turned off, pressing the battery power

button once will display the current battery level.

Powering on: When the DJI Intelligent Battery is turned off, press and hold the power button for 1 second

to turn on the DJI Intelligent Battery.

Powering off: When the DJI Intelligent Battery is turned on, press and hold the power button for 1 second

to turn off the DJI Intelligent Battery.

Tuning Stand

You can use the tuning stand to hold the Ronin-M during setup or for storage. To unfold the tuning

stand, follow the steps below.

1. Hold the tuning stand in the upright position.

2. Remove the lower legs from their vertical position and install them into the bottom base of the stand.

Remove the upper legs from their vertical position and install them into the upper base of the stand.

Be sure the locator slots are lined up.

[

]

[

]

Rear Knob

Mounting Hole
