Ronin-M

User Manual

Getting Started

Socket

DJI Intelligent Battery Functions

Balanced Charging Automatically balances the voltage of each battery cell during charging

Capacity Display Displays current battery levels

Overcharge Protection Charging stops automatically when the battery voltage reaches 16.8V,

preventing overcharge damage

Over-Discharge Protection Discharging stops automatically when battery voltage reaches 12V,

preventing over-discharge damage

Short-Circuit Protection Automatically cuts power supply when a short circuit is detected

Sleep Protection Sleep mode is activated after 20 minutes of inactivity, saving power

Charging Temperature

Detection

The battery will charge only when the temperature is between 0℃ and

55˚C

DJIIntelligentBatterySpecications

Type LiPo

Capacity 14.4V, 1580mAh

Charging Environment Temperature 0℃~40℃

Operating Environment Temperature -10℃~40℃

Charging/Discharging Environment Relative Humidity ＜80%

Read the user manual, disclaimer, and battery safety guidelines before use. Users take full

responsibility for all operations and usage.

Always use DJI approved chargers. DJI takes no responsibility for any consequences

resulting from the use of non-DJI approved chargers.

Charging the DJI Intelligent Battery

1. Connect the charger to a wall socket (100-240V, 50/60Hz).

2. Connect the DJI Intelligent Battery to the charger.

3. The battery level indicator lights display the current charge level as the DJI Intelligent Battery

charges.

4. The DJI Intelligent Battery is fully charged when the battery level indicator lights turn off.

Disconnect the battery from the charger when charging is complete.
