12J900
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5955−10 Assemblies include all parts shown in frames. 03/11/2010
10
562 92613 Bolt
(Governor Control
Lever)
564 690351 Screw
(Control Cover)
564A 691142 Screw
(Control Cover)
564B 698589 Screw
(Control Cover)
578 398153 Wire Assembly
584 697734 Cover−Breather
Passage
585 K691879 Gasket−Breather
Passage
592 690800 Nut
(Rewind Starter)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp−Hose
601A 691038 Clamp−Hose
604 691757 Cover−Control
604A 691344 Cover−Control
604B 790703 Cover−Control
604C 792418 Cover−Control
608 497680 Starter−Rewind
613 691340 Screw
(Muffler)
−−−−−−− Note −−−−−
790833 Screw
(Muffler)
Used on Type No(s).
0137, 0149, 0158.
792678 Screw
(Muffler)
Used on Type No(s).
0140, 0156, 0159.
615 690340 Retainer−Governor
Shaft
616 698801 Crank−Governor
617KDz270344 Seal−O Ring
(Intake Manifold)
621 692310 Switch−Stop
633 Dz691321 Seal−Choke/Throttle
Shaft
633A Dz693867 Seal−Choke/Throttle
Shaft
635
66538S Boot−Spark Plug
635A 793351 Boot−Spark Plug
668 K493823 Spacer
670 692294 Spacer−Fuel Tank
676A 393756 Deflector−Muffler
677 690661 Screw
(Muffler Deflector)
684 690345 Screw
(Breather Passage
Cover)
689 691855 Spring−Friction
692 690572 Spring−Detent
718 690959 Pin−Locating
741 797521 Gear−Timing
(Metal)
(Used After Code Date
08021700).
−−−−−−− Note −−−−−
795755 Gear−Timing
(Plastic)
(Used After Code Date
08021700).
794388 Gear−Timing
(Use Without Woodruff
Key)
(Used After Code Date
07093000 and Before
Code Date 08021800).
790345 Gear−Timing
(Use Without Woodruff
Key)
(Used Before Code
Date 07100100).
691830 Gear−Timing
(Uses Woodruff Key)
745 691648 Screw
(Brake)
832 499034 Guard−Muffler
832B 497683 Guard−Muffler
836 690664 Screw
(Muffler Guard)
836B 690661 Screw
(Muffler Guard)
842 K691031 Seal−O Ring
(Dipstick Tube)
843 691884 Sleeve−Lever
(Speed Control)
843A 691895 Sleeve−Lever
(Choke)
847 692047 Dipstick/Tube
Assembly
851 493880S Terminal−Spark Plug
851A 692424 Terminal−Spark Plug
868 697338 Seal−Valve
869 691155 Seat−Valve
(Intake)
870 690380 Seat−Valve
(Exhaust)
871 262001 Bushing−Valve Guide
(Exhaust)
−−−−−−− Note −−−−−
63709 Bushing−Valve
Guide
(Intake)
883 K∅691881 Gasket−Exhaust
921A 695886 Cover−Blower Housing
921C 695889 Cover−Blower Housing
921E 696262 Cover−Blower Housing
921G 790701 Cover−Blower Housing
921H 790037 Cover−Blower Housing
921J 790036 Cover−Blower Housing
921K 699984 Cover−Blower Housing
921L 791026 Cover−Blower Housing
921P 792687 Cover−Blower Housing
921U 794355 Cover−Blower Housing
922 691831 Spring−Brake
922A 692135 Spring−Brake
923 691994 Brake
923A 695891 Brake
−−−−−−− Note −−−−−
695891 Brake
(Used Before Code
Date 08050100).
Used on Type No(s).
0106.
923B 796136 Brake
(Used After Code Date
08043000).
Used on Type No(s).
0106.
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
Not for
Reproduction
