Деталировка двигателя B_S 12J902 Страница: 7

Тарпан ТМЗ-МК-03 [7/12] Not for reproduction

12J900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5955−7 Assemblies include all parts shown in frames. 03/11/2010

1 697324 Cylinder Assembly

2 399269 Kit−Bushing/Seal

(Magneto Side)

3 K299819S Seal−Oil

(Magneto Side)

4 493279 Sump−Engine

5 691160 Head−Cylinder

7 K∅692249 Gasket−Cylinder Head

8 495786 Breather Assembly

9 K∅699833 Gasket−Breather

10 94650 Screw

(Breather Assembly)

11 691781 Tube−Breather

11B 691923 Tube−Breather

12 K692232 Gasket−Crankcase

13 690912 Screw

(Cylinder Head)

15 691680 Plug−Oil Drain

(Square Socket)

16 691451 Crankshaft

Used on Type No(s).

0106, 0117, 0119,

0120, 0126, 0128,

0129, 0136, 0137,

0143, 0147, 0149,

0158.

−−−−−−− Note −−−−−

694849 Crankshaft

Used on Type No(s).

0111.

691452 Crankshaft

Used on Type No(s).

0112, 0116, 0118,

0121, 0134, 0135,

0142, 0159.

691450 Crankshaft

Used on Type No(s).

0113, 0115, 0122,

0123, 0124, 0125,

0127, 0130, 0131,

0138, 0140, 0141,

0145, 0148, 0156,

4138.

691455 Crankshaft

Used on Type No(s).

0153.

20 K399781S Seal−Oil

(PTO Side)

(Auxiliary PTO)

22 691092 Screw

(Crankcase Cover/

Sump)

23 691987 Flywheel

−−−−−−− Note −−−−−

691992 Flywheel

Used on Type No(s).

0111, 0112.

24 222698S Key−Flywheel

797302 Piston Assembly

(Standard)

(Used After Code Date

09041600).

−−−−−−− Note −−−−−

795429 Piston

Assembly

(Standard)

(Used After Code Date

07090300 and Before

Code Date 09041700).

791096 Piston

Assembly

(Standard)

(Used Before Code

Date 07090400).

797303 Piston

Assembly

(.020” Oversize)

(Used After Code Date

09041600).

795430 Piston

Assembly

(.020” Oversize)

(Used After Code Date

07090300 and Before

Code Date 09041700).

791325 Piston

Assembly

(.020” Oversize)

(Used Before Code

Date 07090400).

26 797304 Ring Set

(Standard)

(Used After Code Date

09041600).

−−−−−−− Note −−−−−

795431 Ring Set

(Standard)

(Used After Code Date

07090300 and Before

Code Date 09041700).

791098 Ring Set

(Standard)

(Used After Code Date

04031400 and Before

Code Date 07090400).

499425 Ring Set

(Standard)

(Used Before Code

Date 04031500).

797305 Ring Set

(.020” Oversize)

(Used After Code Date

09041600).

795432 Ring Set

(.020” Oversize)

(Used After Code Date

07090300 and Before

Code Date 09041700).

791324 Ring Set

(.020” Oversize)

(Used After Code Date

04102100 and Before

Code Date 07090400).

499427 Ring Set

(.020” Oversize)

(Used Before Code

Date 04102200).

27 691588 Lock−Piston Pin

(Used After Code Date

09041600).

−−−−−−− Note −−−−−

691866 Lock−Piston

(Used Before Code

Date 09041700).

K Included in Engine Gasket Set−Ref. No.358.

D Included in Carburetor Overhaul Kit−Ref. No. 121.

z Included in Carburetor Gasket Set−Ref. No. 977.

∅ Included in Valve Gasket Set−Ref. No 1095.

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction
