Тарпан ТМЗ-МК-03 [11/12] 11 assemblies include all parts shown in frames 03 11 2010 11
![Тарпан ТМЗ-МК-03 [11/12] 11 assemblies include all parts shown in frames 03 11 2010 11](/views2/1219681/page11/bgb.png)
12J900
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5955−11 Assemblies include all parts shown in frames. 03/11/2010
11
925 795403 Cover−Linkage
(Used After Code Date
07072200).
−−−−−−− Note −−−−−
690595 Cover−
Linkage
(Used Before Code
Date 07072300).
930 691919 Guard−Rewind
930A 691345 Guard−Rewind
957A 692046 Cap−Fuel Tank
(Plastic)
957B 699985 Cap−Fuel Tank
(Plastic)
958 698183 Valve−Fuel Shut Off
(Plastic)
966A 496116 Base−Air Cleaner
Primer
966B 792040 Base−Air Cleaner
Primer
967A 493537S Filter−Pre Cleaner
968B 692298 Cover−Air Cleaner
969 690700 Screw
(Blower Housing
Cover)
969A 691138 Screw
(Blower Housing
Cover)
970 691669 Screw
(Air Cleaner Primer
Bracket)
972 699392 Tank−Fuel
(Plastic)
972B 699374 Tank−Fuel
(Plastic)
975 493640 Bowl−Float
976 694395 Primer−Carburetor
977 498261 Gasket Set−Carburetor
1005 691346 Fan−Flywheel
1019 494256 Kit−Label
1036 Label−Emissions
(Available From A
Briggs & Statton
Authorized Dealer)
1058
277039 Operator’s Manual
1059 692311 Kit−Screw/Washer
1095 498528 Gasket Set−Valve
1210 498144 Pulley/Spring
Assembly
(Pulley)
1211 498144 Pulley/Spring
Assembly
(Spring)
1319 794467 Label−Warning
1330 270962 Manual−Repair
1386 790848 Vane−Air
(Autochoke System)
1387 790849 Spring−Air Vane
1388 790850 Screw
(Air Vane)
(Autochoke System)
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
Not for
Reproduction
