12J900
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5955−8 Assemblies include all parts shown in frames. 03/11/2010
8
28 298909 Pin−Piston
(Used After Code Date
09041600).
−−−−−−− Note −−−−−
499423 Pin−Piston
(Used Before Code
Date 09041700).
29 797306 Rod−Connecting
(Used After Code Date
09041600).
−−−−−−− Note −−−−−
499424 Rod−
Connecting
(Used Before Code
Date 09041700).
32 691664 Screw
(Connecting Rod)
32A 695759 Screw
(Connecting Rod)
33 262651S Valve−Exhaust
34 262652S Valve−Intake
35 691270 Spring−Valve
(Intake)
36 691270 Spring−Valve
(Exhaust)
37 694086 Guard−Flywheel
40 692194 Retainer−Valve
43 691997 Slinger−Governor/Oil
45 690548 Tappet−Valve
46 691449 Camshaft
50 497465 Manifold−Intake
51 K272199S Gasket−Intake
54 691650 Screw
(Intake Manifold)
55 691421 Housing−Rewind
Starter
58 280399S Rope−Starter
(Cut To Required
Length)
60 281434S Grip−Starter Rope
65 690837 Screw
(Rewind Starter)
73
691221 Screen−Rotating
78 691108 Screw
(Flywheel Guard)
81 691740 Lock−Muffler Screw
95 691636 Screw
(Throttle Valve)
97 493267 Shaft−Throttle
(Metal)
−−−−−−− Note −−−−−
696565 Shaft−Throttle
(Plastic)
104 D691242 Pin−Float Hinge
108 691182 Valve−Choke
108A 795935 Valve−Choke
(Used After Code Date
08031200).
−−−−−−− Note −−−−−
790844 Valve−Choke
(Used Before Code
Date 08031300).
109A 498593 Shaft−Choke
109B 795936 Shaft−Choke
(Used After Code Date
08031200).
−−−−−−− Note −−−−−
790843 Shaft−Choke
(Used Before Code
Date 08031300).
117 494870 Jet−Main
(Standard)
117A 494870 Jet−Main
(Standard)
117B 498977 Jet−Main
(Standard)
(Used After Code Date
08061900).
−−−−−−− Note −−−−−
691428 Jet−Main
(Standard)
(Used Before Code
Date 08062000).
118 497315 Jet−Main
(High Altitude)
118A 497315 Jet−Main
(High Altitude)
1
18B 694250 Jet−Main
(High Altitude)
(Used After Code Date
08061900).
−−−−−−− Note −−−−−
695042 Jet−Main
(High Altitude)
(Used Before Code
Date 08062000).
121 498260 Kit−Carburetor
Overhaul
125 698444 Carburetor
(Primer System)
125A 690000 Carburetor
(Choke System)
125B 794304 Carburetor
(Autochoke System)
127 D694468 Plug−Welch
(3/8” Diameter)
130 691203 Valve−Throttle
−−−−−−− Note −−−−−
696564 Valve−Throttle
(Used With Plastic
Throttle Shaft)
133 398187 Float−Carburetor
134 D398188 Kit−Needle/Seat
137 Dz693981 Gasket−Float Bowl
146 690979 Key−Timing
159 691753 Bracket−Air Cleaner
Primer
163KDz272653 Gasket−Air Cleaner
187 791766 Line−Fuel
(Cut to Required
Length)
187A 791873 Line−Fuel
(Molded)
188 690877 Screw
(Control Bracket)
190 690940 Screw
(Fuel Tank)
202 691829 Link−Mechanical
Governor
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
