Тарпан ТМЗ-МК-03 [9/12] Illustrations cover a range of engines parts shown without corresponding text may not be used on your specific engine
![Тарпан ТМЗ-МК-03 [9/12] Illustrations cover a range of engines parts shown without corresponding text may not be used on your specific engine](/views2/1219681/page9/bg9.png)
12J900
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5955−9 Assemblies include all parts shown in frames. 03/11/2010
9
209 691291 Spring−Governor
Used on Type No(s).
0106, 0117.
−−−−−−− Note −−−−−
691290 Spring−
Governor
Used on Type No(s).
0111.
691292 Spring−
Governor
Used on Type No(s).
0112, 0115, 0116,
0118, 0119, 0120,
0121, 0124, 0128,
0134, 0136, 0142,
0143, 0149, 0153,
0158.
691851 Spring−
Governor
Used on Type No(s).
0113, 0122, 0123,
0125, 0126, 0127,
0130, 0131, 0135,
0138, 0140, 0141,
0145, 0147, 0148,
0156, 4138.
699056 Spring−
Governor
Used on Type No(s).
0129, 0159.
691852 Spring−
Governor
Used on Type No(s).
0137.
222 790143 Bracket−Control
(Remote/Manual
Friction)(Primer)
222C 692150 Bracket−Control
(Variable Speed)
(5 Position Manual
Choke)
222D 791128 Bracket−Control
(Fixed Speed)
227 690783 Lever−Governor
Control
231 691636 Screw
(Choke Valve)
236 691826 Link−Lockout
265 690798 Clamp−Casing
265A 691024 Clamp−Casing
267 691044 Screw
(Casing Clamp)
268 691025 Casing−Control Wire
(Cut To Required
Length)
269 691026 Wire−Control
(Cut To Required
Length)
270 691027 Nut
(Control Wire Casing)
271 691028 Lever−Control
276 Dz271716
Washer−Sealing
287
690940 Screw
(Dipstick Tube)
291 790830 Thermostat
300 692038 Muffler
−−−−−−− Note −−−−−
790828 Muffler
Used on Type No(s).
0137, 0149, 0158.
792677 Muffler
Used on Type No(s).
0140, 0156, 0129.
304 695892 Housing−Blower
Used on Type No(s).
0106, 0115, 0116,
0117, 0118, 0119,
0123, 0135, 0141,
0145, 4138.
−−−−−−− Note −−−−−
493294 Housing−
Blower
Used on Type No(s).
0111, 0112, 0113,
0122, 0125, 0126,
0128, 0129, 0130,
0131, 0134, 0136,
0142, 0143, 0147,
0153.
493293 Housing−
Blower
Used on Type No(s).
0120, 0121, 0124,
0138.
790826 Housing−
Blower
Used on Type No(s).
0137, 0149, 0158.
791291 Housing−
Blower
Used on Type No(s).
0140, 0156, 0159.
305 691108 Screw
(Blower Housing)
306 690450 Shield−Cylinder
306A 790836 Shield−Cylinder
307 690345 Screw
(Cylinder Shield)
332 690662 Nut
(Flywheel)
333 802574 Armature−Magneto
−−−−−−− Note −−−−−
790817 Armature−
Magneto
Used on Type No(s).
0137, 0149, 0158.
333A 793353 Armature−Magneto
334 691061 Screw
(Magneto Armature)
337 802592S Plug−Spark
(Resistor)
−−−−−−− Note −−−−−
697451 Plug−Spark
(EMS)
356
692390 Wire−Stop
356C 690808 Wire−Stop
358 497316 Gasket Set−Engine
363 19069 Flywheel Puller
365 691688 Screw
(Carburetor)
383 89838S Wrench−Spark Plug
404 690272 Washer
(Governor Crank)
425A 690670 Screw
(Air Cleaner Cover)
443A 692523 Screw
(Air Cleaner Primer
Base)
445A 491588S Filter−Air Cleaner
Cartridge
455 791960 Cup−Flywheel
456 692299 Plate−Pawl Friction
459 281505S Pawl−Ratchet
505 691251 Nut
(Governor Control
Lever)
523 499621 Dipstick
524 K692296 Seal−Dipstick Tube
525 495265 Tube−Dipstick
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
Not for
Reproduction
