Table 11. Light path diagnostics panel LEDs (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem is
solved.
v If a action step is preceded by "(Trained technician only)," that step must be performed only by a trained
technician.
LED Description Action
CONFIG A hardware configuration error
has occurred.
1. If the CONFIG LED and the CPU LED are lit, complete
the following steps to correct the problem:
a. Check the microprocessors that were just installed to
make sure that they are compatible with each other
(see “Replacing a microprocessor and heat sink” on
page 349 for additional information about
microprocessor requirements).
b. (Trained technician only) Replace the incompatible
microprocessor.
c. Check the system-event logs for information about the
error. Replace any components that are identified in
the error log.
2. If the CONFIG LED and the MEM LED are both lit,
complete the following steps:
a. Make sure that the DIMM configuration is supported
(see “Installing a memory module” on page 34 for
DIMM requirements and installation sequence
information).
b. Replace the DIMMs with a supported configuration.
Chapter 4. Troubleshooting 111
