Intel r2208gl4gs [14/22] General installation process
![Intel r2224gz4gc4 [14/22] Softwar](/views2/1219990/page14/bge.png)
10
General Installation Process
22
Software
• BIOS, Drivers, and Operating System Installation
B. Configure your RAID Controller:
C. Install your Operating System:
D. Install Operating System Drivers:
A. Update the System Software:
E. Install Intel® System Management Software (optional):
Update the System BIOS, ME Firmware, BMC Firmware, and FRU & SDR data, using the latest versions posted for this product at
http://www.intel.com/support.
If using a RAID card, use the instructions provided with the RAID controller. If using on-board RAID, you must activate RAID in the BIOS setup. See the Intel
®
Server System
R2000GZ/GL Service Guide for more information.
Use the instructions provided with the RAID controller and with the operating system.
With the operating system running, insert the Intel
®
Server Deployment & Management DVD. If using a Microsoft Windows* operating system, the Express Installer will
autorun and allow you to select the appropriate drivers to install. On other operating systems, browse the DVD folders to locate and install the driver files.
Download the latest version of the Intel
®
System Management Software from http://www.intel.com/go/servermanagement and use the instructions provided at that link to
install the software.
NOTE: The FRUSDR utility must be run for full platform management functionality.
* Other brands and names may be claimed as the property of others.
