1
System Overview
Intel® Server System R2000GZ/GL Product Family
Useful Information:
• Riser Slot 2 is not functional without having two processors installed.
• The SCU1 (4-7) port requires an Intel
®
RAID C600 Upgrade Key installed to be functional.
System Features and Components
* 2.5" Hard Drive Bay system as shown
Hot Swap
Hard Drive Bays
System Fans
CPU1
CPU2
Add-in Card Riser Assembly
1+1 Redundant
Power Supply
Modules
Server Board
Air Duct
Optical Drive Bay
Front Control Panel
