ENGLISH 75
❏ FM tuner section
Frequency Range 87.9 MHz to 107.9 MHz (200 kHz)
87.5 MHz to 108.0 MHz (50 kHz)
Usable Sensitivity (S/N: 30 dB, 22.5 kHz)
7.2 dBf (0.63 μV/75 Ω)
Quieting Sensitivity (S/N: 46 dB, 22.5 kHz)
15.2 dBf (1.58 μV/75 Ω)
Frequency Response (±3.0 dB)
30 Hz to 15 kHz
Signal to Noise Ratio
68 dB (MONO)
Selectivity (±400 kHz)
≥ 80 dB
Stereo Separation 40 dB (1 kHz)
❏ AM tuner section
Frequency Range 530 kHz to 1 700 kHz (10 kHz)
531 kHz to 1 611 kHz (9 kHz)
Usable Sensitivity 29 dBμ
❏ Video section
Color System of External Video Input
NTSC/PAL
External Video Input Level (RCA/mini jack)
1 Vp-p/75 Ω
Video Output Level (RCA jack)
1 Vp-p/75 Ω
❏ Audio section
Maximum Power (Front & Rear)
50 W × 4
Full Bandwidth Power (Front & Rear)
22 W × 4 (at less than 1%THD)
Preout Level 4 V/10 kΩ
Preout Impedance ≤ 600 Ω
Speaker Impedance
4 Ω to 8 Ω
❏ General
Operating Voltage
14.4 V (10.5 V to 16 V allowable)
Maximum Current Consumption
10 A
Installation Dimensions (W × H × D)
KW-V420BT Region 1/KW-V320BT Region 1
KW-V220BT Region 1/KW-V120BT:
178 mm × 100 mm × 162 mm
(7-1/16" × 3-15/16" × 6-7/16")
KW-V420BT Region 4:
182 mm × 111 mm × 165 mm
(7-3/16" × 4-3/8" × 6-1/2")
KW-V320BT Region 4/KW-V220BT Region 4:
182 mm × 111 mm × 160 mm
(7-3/16" × 4-3/8" × 6-5/16")
Operational Temperature Range
–10°C to +60°C
Weight
KW-V420BT Region 1: 2.3 kg (5.1 lbs)
KW-V420BT Region 4: 2.6 kg ( 5.8 lbs)
KW-V320BT Region 1/KW-V220BT Region 1/
KW-V120BT: 1.6 kg (3.6 lbs)
KW-V320BT Region 4/KW-V220BT Region 4:
1.9 kg ( 4.2 lbs)
Design and specifications are subject to change
without notice.
