72
❏ HDMI interface section
Connector Type TYPE-A
❏ MHL interface section
Supported Version
MHL 2
Maximum Power Supply Current
DC 5 V
900 mA
❏ Bluetooth section
Technology Bluetooth 3.0 + EDR
Frequency 2.402 GHz to 2.480 GHz
Output Power +4 dBm (MAX), 0 dBm (AVE),
Power Class 2
Maximum Communication Range
Line of sight approx. 10 m
Audio Codec SBC/AAC/MP3
Profile HFP (Hands Free Profile) V1.6
A2DP (Advanced Audio
Distribution Profile) V1.2
AVRCP (Audio/Video Remote
Control Profile) V1.5
GAP (Generic Access Profile)
PBAP (Phone Book Access Profile)
SDP (Service Discovery Profile)
SPP (Serial Port Profile) V1.2
❏ DSP section
Graphics equalizer
BAND 7 Band
Frequency (Hz) (BAND1-7)
62.5/160/400/1k/2.5k/6.3k/16k
Gain –9/–8/–7/–6/–5/–4/–3/–2/
–1/0/1/2/3/4/5/6/7/8/9 dB
2 Way X'Over
HIGH PASS FILTER frequency
Through/50/60/80/100/120/150/
180/220
SLOPE –6/–12/–18/–24 dB/Oct.
LOW PASS FILTER frequency
50/60/80/100/120/Through
SLOPE –6/–12/–18/–24 dB/Oct.
Position
Front/Rear/Subwoofer Delay
0 cm to 610 cm (2.0 cm Step)
Gain –8 dB to 0 dB
Subwoofer Level –50 dB to +10 dB
❏ FM radio section
Frequency Range (50 kHz)
87.5 MHz to 108.0 MHz
Usable Sensitivity (S/N: 30 dB)
6.2 dBf ( 0.56 μV/75 Ω)
Quieting Sensitivity (S/N: 50 dB)
15.2 dBf (1.58 μV/75 Ω)
Frequency Response (±3.0 dB)
30 Hz to 15 kHz
Signal to Noise Ratio
68 dB (MONO)
Selectivity (±400 kHz)
≥ 80 dB
Stereo Separation 40 dB (1 kHz)
❏ LW tuner section
Frequency Range (9 kHz)
153 kHz to 279 kHz
Usable Sensitivity 45 μV
❏ MW tuner section
Frequency Range (9 kHz)
531 kHz to 1 611 kHz
Usable Sensitivity 28.5 μV
REFERENCESREFERENCES
