OKI ml395 [15/79] Changing paper paths
![OKI ml395 [15/79] Changing paper paths](/views2/1222327/page15/bgf.png)
Changing Paper Paths
Changing Paper Paths
You don't have to remove continuous-form paper in order to print a single sheet.
To change from continuous forms to single sheets:
1. Remove any printed pages from printer.
2. Press PARK button to retract continuous forms paper from paper path.
3. Move paper lever to single sheet position if you're switching from rear feed.
4. Lift paper support to upright position and align left paper guide with paper icon on support.
5. Insert a piece of single-sheet paper and adjust right paper guide to width of paper.
6. Press FORM FEED button to feed sheet into printer.
ML395 ( 96-02-07 )
