Set Page Length
in Lines
ASCII: ESC C n
Dec: 27 67 n
Hex: 1B 43 n
Sets page length in lines. Current position becomes
top of form. Printer calculates page length by
multiplying current line feed pitch by value entered
for ``n.''
n = 1 to127.
Cancels Skip over Perforation setting.
Page length set by this command will not change
even if line spacing is changed.
Set Page Length
in Inches
ASCII: ESC C NUL n
Dec: 27 67 0 n
Hex: 1B 43 00 n
Sets page length in"es. Current position becomes top
of form.
n = 1 to 22.
Cancels Skip over Perforation setting.
Set Skip Over
Perforation area
(bottom margin)
ASCII: ESC N n
Dec: 27 78 n
Hex: 1B 4E n
Activates Skip Over Perforation feature and sets it
for n lines at the current line spacing. When
Perforation Skip area is entered, printer will
automatically feed paper down to top of form on
next page. Once this command is entered, the Skip
Over Perforation setting will remain the same even if
line spacing is changed.
n = 1 to 255
Cancel Skip Over
Perforation
ASCII: ESC O
Dec: 27 79
Hex: 1B 4F
Deactivates Skip Over Perforation. Command
overrides menu.
Cut Sheet Feeder
Option
Cut Sheet Feeder
Control
ASCII: ESC EM n
Dec: 27 25 n
Hex: 1B 19 n
Controls Cut Sheet Feeder accessory.
n = 1: Select bin 1
n = 2: Select bin 2 (if present)
n = 73 (ASCII ``I''): Insert sheet
n = 82 (ASCII ``R''): Eject sheet
Character Sets
Download Custom
Characters
ASCII: ESC & m n
1
n
2
d
0
d
1
d
2
[data]
Dec: 27 38 109 n
1
n
2
d
0
d
1
d
2
[data]
Hex: 1B 26 6D n
1
n
2
d
0
d
1
d
2
[data]
n
1
= 0 to 127
n
2
= 0 to 127
n
1
n
2
, range of characters to be replaced
d
0
= 0 to 255: clearance before character
d
1
= 0 to 37: number of columns character occupies
d
2
= 0 to 255: clearance after character
Copy ROM
Character Set to
RAM Character Set
ASCII: ESC : NUL m n
Dec: 27 58 0 m n
Hex: 1B 3A 00 m n
Copies ROM characters 32 to 127 to RAM 32 to 127
m = 0: Roman
m = 1: Swiss
m = 2: Courier
m = 3: Prestige
m = 7: Orator
m = 122: Swiss Bold
m = 124: Gothic
m = 126: Menu setting
n = 0
Select DLL Block
ASCII: ESC v n
Dec: 27 118 n
Hex: 1B 76 n
n = 1: Block 1
n = 2: Block 2
n = 0: command ignored
