Explanation of Menu Items

These explanations are in alphabetical sequence to make it easier to look them up. Some of the items

apply only to a specific emulation, model, or if you are using the Serial Interface, as noted.

Auto LF.

Change to Yes if your printer prints one line over another. Keep this set to No if your software adds a line

feed when a carriage return is received at the end of a line or if your printout is consistently double

spaced.Auto CR (IBM mode only). Choose Yes to make your printer automatically perform a carriage

return when an LF is received at the end of the line.

Auto Feed XT

(Epson mode only). In the Epson emulation, the XT signal on pin 14 of the parallel interface can control

auto-matic line feed. Some interface cables are wired in such a way that automatic line feed is always in

effect; the Auto Feed XT item eliminates this potential problem. The factory setting allows your system to

use pin 14 to control automatic line feed; to cause the printer to ignore this signal, change the setting to

Invalid.

Baud Rate (Serial Interface only).

Choose a transmission rate of 19,200 bps, 9600 bps (factory default), 4800 bps, 2400 bps, 1200 bps, 600

bps, or 300 bps.

Busy Line (Serial Interface only).

If Ready/Busy protocol (factory default) is selected, you can choose which line your system monitors for a

busy signal: SSD -9V, select SSD-SSD +9V, select SSD+ DTR -9V, select DTR RTS -9V, select RTS

Busy Time (Serial Interface only).

Choose 200 mS (factory default) or 1 sec. Sets the length of the busy signal when the Ready/Busy

protocol (factory default) is engaged.

Character Set.

Choose IBM Set I (factory default), IBM Set II, or Epson character set.

Code Page. Choose USA (factory default), Multilingual, or Canada French.

CPU Compensation.

Used to adjust interface timing between your PC and the printer. Do not change this setting unless

advised to by an Okidata-Certified Technician.

Diagnostic Test (Serial Interface only).

Select Yes if you want to perform a diagnostic test of the serial interface.

DSR Signal (Serial Interface only).

Used with Ready/Busy protocol to select how your system handles the DSR Signal.DTR Signal (Serial

Interface only). Change to •Ready on Select• if the DTR signal is required when the printer is selected;

leave as •Ready on Power Up• if DTR signal is required when printer is turned on.

Emulation Mode.

Selects the printer command set you want your printer to use: Epson LQ 1000/1050/2500/2550, IBM

XL24 Proprinter, or IBM XL24 Alternate Graphics Mode (AGM).

Form Tear Off.

Off (factory default), 300 ms, 2 sec, 4 sec, offline, 300 ms (ML393PLUS), 1 sec (ML393PLUS), 2 sec

ML393PLUS). To engage Form Tear Off, select a time interval for the printer to wait before advancing the

paper. Choose one of the ML393PLUS settings to provide backward compatibility with programs written

for the Microline 393 Plus printer. Choose offline to cause your printer to go offline after moving the paper
