INSTALLATION OF THE COOKING HOB
These Instructions are for the qualified technician, as a
guide to the installation, adjustment and maintenance,
according to the laws and standards in force.
Any of these operations must always be carried out when
the appliance has been disconnected from the electric
system.
The appliance can be fitted into a working area as
illustrated on the figure. Apply the seal supplied over the
whole perimeter of the working area.
580
510
560
490
45
270
494
288
510
450
40
490
470 510
