1-6
X10SRi-F User’s Manual
Motherboard Features
CPU Single Intel
®
E5-2600/1600 Series processor in an
LGA2011 R3 socket.
Note: Both E5-2600v4 and E5-1600v4 re-
quire Revision 2.0 BIOS (or higher).
Memory Eight (8) slots support up to 256GB of RDIMM and 512GB
of LRDIMM DDR4 ECC 2400 MHz (max.) memory
Dual-channel memory
DIMM sizes
RDIMM 1GB, 2GB, 4GB, 8GB, 16GB, 32GB
Chipset Intel
®
C612 Express
Expansion Slots Two (2) PCI Express 2.0: 1 (x4 in x8), 1 (x2 in x8)
Four (4) PCI Express 3.0: 1 (x16), 1 (x4 in x8), 2 (x8)
Two (2) RJ-45 rear I/O panel connectors with Link and
Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s)
Ten (10) SATA3 ports
• AHCI controller supports six (6)
SATA3 drives compatible with
RAID 0, 1, 5, 10.
• sSATA controller supports four
(4) SATA3 drives compatible
with RAID 0, 1, 5, 10.
• RAID array and volume(s) can-
not span across the two (AHCI
and sSATA) controllers.
SATA DOM Two (2) SATA DOM Ports (SATA 4/5)
USB Devices
• Four (4) USB 3.0 ports (2 rear, 1 Type-A, 1
header)
• Eight (8) USB 2.0 (2 rear, 6 headers)
Two (2) Front Accessible USB 2.0 ports on one header
(USB 8/9)
Serial (COM) Ports
Two (2) COM Ports (1 rear, 1 header)
Graphics Controller
AST 2400 Graphics Controller
