4-24

X10SRi-F User’s Manual

• ME Firmware Status #2

• Current State

• Error Code

PCIe/PCI/PnP Conguration

The following PCI information will be displayed:

• PCI Bus Driver Version

• PCI Latency Timer

VGA Palette Snoop

Select Enabled to support VGA palette register snooping which will allow a PCI

card that does not contain its own VGA color palette to examine a video card pal-

ette and mimic it for proper color display. The options are Disabled and Enabled.

PCI AER (Advanced Error-Reporting) Support

Select Enabled to support Advanced Error-Reporting for onboard PCI devices. The

options are Disabled and Enabled.

Above 4G Decoding (Available if the system supports 64-bit PCI decoding)

Select Enabled to decode a PCI device that supports 64-bit in the space above 4G

Address. The options are Enabled and Disabled.

SR-IOV Support (Available if the system supports Single-Root

Virtualization)

Select Enabled for Single-Root IO Virtualization support. The options are Enabled

and Disabled.

Maximum Payload

Select Auto for the system BIOS to automatically set the maximum payload value

for a PCI-E device to enhance system performance. The options are Auto, 128

Bytes and 256 Bytes.

Maximum Read Request

Select Auto for the system BIOS to automatically set the maximum size for a read

request for a PCI-E device to enhance system performance. The options are Auto,

128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.
