Chapter 1: Introduction
1-9
1-2 Chipset Overview
The X10SRi-F supports a single Intel
®
E5-2600/1600 Series Processor in an
LGA2011 R3 socket. Built upon the functionality and the capability of the Intel
®
C612 Express chipset, the motherboard provides substantial enhancement to
system performance and storage capability for high performance platforms in a
sleek package.
The high-speed Direct Media Interface (DMI) featured in the Intel
®
C612 Express
chipset supports high-speed Direct Media Interface (DMI) for chip-to-chip true
isochronous communication, providing up to 5 Gb/s of software-transparent data
transfer rate on each read/write direction. In addition, the X10SRi-F also features
a TCO timer which allows the system to recover from a software/hardware lock
and perform tasks, including Function Disable and Intruder Detect.
Intel C612 Express Chipset Features
• Direct Media Interface (up 5 Gb/s transfer, Full Duplex)
• Dual NAND Interface
• Intel
®
I/O Virtualization (VT-d) Support
• Intel
®
Trusted Execution Technology Support
• PCI Express 2.0 Interface (up to 5.0 GT/s)
• SATA Controller (up to 6Gb/sec)
• Advanced Host Controller Interface (AHCI)
• Intel
®
Active Management Technology (iAMT) 9.0 and vPRO 9.0 support
Note: Both E5-2600v4 and E5-1600v4 require Revision 2.0 BIOS (or
higher).
