Chapter 2: Installation
2-25
DESIGNED IN USA
1.01REV:
X10SRi-F
JP3
JTPM1
JF1
JD1
J23
T-SGPIO1
T-SGPIO2
T-SGPIO3
JOH1
JL1
JPME2
JWD1
JPG1
JPB1
1
JI2C2
JI2C1
JBR1
JVRM2
JVRM1
JPL1
JSD1
JSD2
JIPMB1
JPWR1
JUIDB1
LE1
LE2
LEDM1
JBT1
BT1
FAN4
FAN1
FAN2
F
AN3
FANA
FAN5
J24
JPI2C1
JSTBY1
S-SATA3
I-SATA4
I-SATA0
I-SATA1
I-SATA2
I-SATA3
S-SATA0
S-SATA1
S-SATA2
I-SATA5
SP1
1-2:ENABLE
2-3:DISABLE
JPB1:BMC
CPU
CPU SLOT5 PCI-E 3.0 X4(IN X8)
CPU SLOT4 PCI-E 3.0 X8
CPU SLOT3 PCI-E 3.0 X8
JPME2
2-3:ME MANUFACTURUNG MODE
1-2:Normal
USB0/1
DIMMC2
PWR LED1-3:
JD1:
SPEAKER4-7:
JBR1
1-2:Normal
2-3:BIOS recovery
:TPM/PRO80
USB8/9
USB6/7
LED
NMI
PWR
X
USB2/3
(3.0)
HDD
NIC
1
JWD1:Watch Dog
1-2:RST
2-3:NMI
LAN1
DIMMA2
DIMMA1
USB10(3.0)
FF
2
NIC
OH
LAN2
RST
PWR
PWR
FAIL
USB4/5
ON
1-2:ENABLE
2-3:DISABLE
JPG1:VGA
JI2C1/JI2C2
I2C bus for PCI-E slot
OFF:DISABLE
ON: ENABLE
PCH SLOT2 PCI-E 2.0 X4(IN X8)
PCH SLOT1 PCI-E 2.0 X2(IN X8)
COM2
COM1
DIMMB2
DIMMB1
PWR I2C
DIMMD2
DIMMD1
DIMMC1
IPMI_LAN
UID
USB11(3.0)
0N: POWER FORCE ON
JPL1:LAN1/2
1-2:ENABLE
VGA
2-3:DISABLE
LGA2011-3
1
1
CPU SLOT6 PCI-E 3.0 X16
BAR CODE
IPMI CODE
MAC CODE
BIOS
LICENSE
BIOS
2-7 Connecting Cables
This section provides brief descriptions and pin-out denitions for onboard headers
and connectors. Be sure to use the correct cable for each header or connector.
For information on Backpanel USB and Front Panel USB ports, refer to page 2-17.
A. 24-Pin ATX Main PWR
B. 8-Pin PWR
ATX Power 24-pin Connector
Pin Denitions (JPW1)
Pin# Denition Pin # Denition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 COM 3 COM
16 PS_ON 4 +5V
17 COM 5 COM
18 COM 6 +5V
19 COM 7 COM
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 COM 12 +3.3V
(Required)
12V 8-pin Power Connec-
tor Pin Denitions
Pin# Denition
1 through 4 Ground
5 through 8 +12V
ATX Main PWR & CPU PWR
Connectors (J24 & JPWR1)
The 24-pin main power connector
(J24) is used to provide power to the
motherboard. The 8-pin CPU PWR
connector (JPWR1) is also required
for the processor. These power
connectors meet the SSI EPS 12V
specication. See the table on the
right for pin denitions.
24-Pin Main PWR
A
B
