![Frico sf18e09 [11/20] Safety forallinstallationsofelectricallyheated products should a residual current circuit breaker 300 ma for fire protection be used keep the areas around the air intake and exhaust grilles free from possible obstructions duringoperationthesurfacesoftheunit are hot theunitmustnotbefullyorpartially covered with textiles or similar materials as overheating can result in a fire risk thisapplianceisnotintendedforuseby persons including children with reduced physical or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety children should be supervised to ensure that they do not play with the appliance](/views2/1230806/page11/bgb.png)
SF E
11
GB
Type Output
stages
[kW]
Airflow
[m
3
/h]
Sound
level*
1
[dB(A)]
∆t*
2
[°C]
Voltage [V]
Amperage [A]
(control)
Voltage [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
SF18E09
0/6/90/6/9 1800 55 15 230V~/2,52A 400V3~/13A 2200
*3
110
(SF1-2200E12) 0/9/12 1800 55 15 230V~/2,52A 400V3~/17,5A 2200
*3
110
SF24E12 (or SF2-2200E12) 0/8/12 2400 56 15 230V~/3,36A 400V3~/17,5A 2200
*3
116
SF36E18 (or SF3-2200E18) 0/12/18 3600 57 15 230V~/4,48A 400V3~/26A 2200
*3
122
SF54E30
0/20/30 5400 57 17 230V~/6,72A 400V3~/43,5A 2200
*3
110
*1) Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent absorption area: 200 m2.
*2) ∆t = temperature rise of passing air at maximum heat output and highest airflow.
*3) Extension possible up to 3900 mm (extension without fans).
not being used for extended periods of time.
Safety
• Forallinstallationsofelectricallyheated
products should a residual current circuit
breaker 300 mA for fire protection be used.
• Keep the areas around the air intake
and exhaust grilles free from possible
obstructions!
• Duringoperationthesurfacesoftheunit
are hot!
• Theunitmustnotbefullyorpartially
covered with textiles, or similar materials,
as overheating can result in a fire risk!
• Thisapplianceisnotintendedforuseby
persons (including children) with reduced
physical or mental capabilities, or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by
a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.
Technical specifications |
Thermozone SF E
