Vitek VT-8101 BK [5/20] English

E N G L I S H

USING THE VACUUM CLEANER

ATTENTION! You may switch the vacuum

cleaner on only with the dust bin (3) and the

separator with HEPA filter (4) installed. Before

switching the vacuum cleaner on always make

sure that the separator with HEPA filter (4) is

installed properly.

– Before using the unit, unwind the power

cord to its full length and insert the power

plug into the mains socket.

Note: You can adjust the power cord length,

if necessary, and store the excessive cord at

the cord storage (9).

– You can use the unit as a compact vacuum

cleaner and extend the handle (8) to the full

length during the room cleaning by press-

ing the clamp button (7).

– Press the on/off button (6) «0/I» to switch

the vacuum cleaner on.

– After room cleaning switch the vacuum

cleaner off by pressing the on/off but-

ton (6) «0/I» and unplug the unit.

– To wind the power cord use the cord stor-

age (9).

CLEANING THE VACUUM CLEANER

It is recommended to clean the vacuum

cleaner after every use. Before cleaning the

vacuum cleaner, switch it off by pressing the

on/off button (6) «0/I» and unplug it.

Cleaning the separator and the HEPA

filter (4), cleaning the dust bin (3)

– Holding the handle (8), push the but-

ton (7) and pull the handle (8) upward

until bumping.

– Remove the handle (1) by pulling it down-

wards.

– Turn the dust bin (3) counterclockwise and

detach it from the motor unit (12).

– Place the dust bin (3) above the garbage

bin. Open the lid of the dust bin (3) flask by

pressing the lid clamp (2). Remove accu-

mulated dust and garbage from the dust

bin (3).

Note: You can remove dust and garbage

during the operation without removing the

dust bin (3), but you have to preliminary

remove the brush (1) and then open the lid

to remove the garbage from the dust bin (3)

by pressing the clamp (2).

– Take the HEPA filter and pull it upwards to

remove the HEPA filter with the separa-

tor (4) from the dust bin (3). Remove the

dust and garbage from the separator with

a suitable brush.

– Take the separator with one hand and turn

the HEPA filter counterclockwise with other

hand and then remove the HEPA filter from

the separator (4).

– Remove the dust and garbage from the

HEPA filter with a suitable brush.

– Wash the separator (4), the HEPA filter and

the dust bin (3) under a warm water jet and

dry them thoroughly.

– Install the HEPA-filter into the separator (4)

turning it clockwise until bumping.

– Install the separator (4) with the installed

HEPA filter into the dust bin (3). To do

this, match the groove on the separator

(4) with the ledge on the dust bin (3) and

install the separator into the dust bin (3)

until bumping.

– To install the dust bin (3) back to its place

match the grooves on the dust bin (3)

with the ledges on the motor unit (12)

and turn the dust bin (3) clockwise until

bumping.

– Press the clamp (11), move the handle (8)

down until the clamp (7) clicking.

Cleaning the brush (1)

– It is also recommended to clean the brush

(1) as it becomes dirty.

– Remove the brush (1) from the brush

installation place (13), clean the brush (1)

and install it back to its place.

Motor unit (12)

• Clean the vacuum cleaner motor unit (12)

with a soft, slightly damp cloth and then

wipe it dry.

• Do not immerse the motor unit (12), the

power cord and the plug into water or any

other liquids. Provide that no liquid gets

inside the motor unit (12).

• Never use solvents or abrasives to clean

the surface of the vacuum cleaner.

IM VT-8101.indd 5 01.09.2016 8:57:30

Vitek VT-8101 BK [5/20] English
