Gigabyte GA-Z97N-Gaming 5 [20/80] Center subwoofer speaker out jack

Hardware Installation

- 20 -

Activity LED

Connection/

Speed LED

LAN Port

Activity LED:Connection/Speed LED:

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

State Description

Blinking Data transmission or receiving is occurring

Off No data transmission or receiving is occurring

Triple-DisplayCongurationsfortheOnboardGraphics:

Triple-displaycongurationsaresupportedafteryouinstallmotherboarddriversinOS.Onlydual-display

congurationsaresupportedduringtheBIOSSetuporPOSTprocess.

DisplayPort

DisplayPort delivers high quality digital imaging and audio, supporting bi-directional audio transmission.

DisplayPort can support both DPCP and HDCP content protection mechanisms. You can use this port to

connectyourDisplayPort-supportedmonitor.Themaximumsupportedresolutionis4096x2160@24Hz

or3840x2160@60Hz,buttheactualresolutionssupportedaredependentonthemonitorbeingused.

eSATA 6Gb/s Connector

(Note)

ThisconnectorsupportsSATA6Gb/sspecication.UsetheporttoconnectanexternalSATAdevice.

USB 3.0/2.0 Port

TheUSB3.0portsupportstheUSB3.0specicationandiscompatibletotheUSB2.0/1.1specication.

Use this port for USB devices Use this port for USB devices such as a USB keyboard/mouse, USB printer,

USBashdriveandetc.

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

Center/Subwoofer Speaker Out Jack

Usethisaudiojacktoconnectcenter/subwooferspeakersina5.1/7.1-channelaudioconguration.

Rear Speaker Out Jack

Thisjackcanbeusedtoconnectfrontspeakersina4/5.1/7.1-channelaudioconguration.

Side Speaker Out Jack

Usethisaudiojacktoconnectsidespeakersina7.1-channelaudioconguration.

Line In Jack

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

In Windows 8.1, select Apps>Control Panel>Hardware

andSound>Sound>Playback,setIntel(R)DisplayAudio

to the default playback device.

(Note) Actualtransferrateisdependentonthedevicebeingconnected.
