PRIME X299-A specifications summary
(continued on the next page)
Storage
Intel
®
X299 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage
Technology 15 support
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 4 mode)
- 1 x M.2_2 Socket 3 with vertical M Key, type 2242/2260/2280/22110
(Support PCIe storage device only)
- Ready for Intel
®
Optane™ Memory
- 8 x SATA 6.0 Gb/s ports*
- Supports Intel
®
Smart Response Technology
* SATA6G_5/6/7/8 ports share bandwidth with PCIEx4_2.
Audio
Realtek
®
S1220A 8-channel high definition audio CODEC featuring
Crystal Sound 3
- Power pre-regulator reduces power input noise to ensure consistent
performance
- Separate layer for left and right track, ensuring both sound deliver equal
quality
- Impedance sense for front and rear headphone outputs
- Audio shielding ensures precise analog/digital separation and greatly
reduced multi-lateral interference
- EMI protection cover to prevent electrical noise to affect the amplier
quality
- Internal audio Amplier to enhance the highest quality sound for
headphone and speakers
- Unique de-pop circuit to reduce start-up popping noise to audio outputs
- Premium Japan-made audio capacitors provides warm, natural, and
immersive sound with exceptional clarity and delity
- High quality 120dB SNR stereo playback output (Line-out@back) & 113dB
SNR input (Line-in) support
- Supports up to 32-Bit/192kHz playback*
- DTS
®
Headphone:X™
- DTS
®
Connect
- Supports jack-detection, multi-streaming, front panel jack-retasking (MIC)
- Optical S/PDIF out port at back I/O
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio. 32-Bit/192kHz is only available under Windows® 10.
