xi
PRIME Z270-AR specifications summary
(continued on the next page)
ASUS Exclusive
Features
<Superb Performance>
OC Design: ASUS PRO Clock Technology
- Full BCLK range for extreme overclocking performance.
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates better
CPU performance, power saving, digital power control, system cooling and
app usages.
DIGI+ Power Control
- CPU Power: Digital 8-phase power design
- iGPU Power: Digital 2-phase power design
TPU
- Auto Tuning, GPU Boost
EPU
- EPU
Fan Xpert 4 featuring Fan Auto Tuning function and multiple
thermistors selection for optimized system cooling control
Turbo App featuring system performance tuning, network priority, and
audio scene conguration for selected applications
UEFI BIOS
CrashFree BIOS 3
EZ Flash 3
EZ Tuning Wizard
GPU Post
S.M.A.R.T.
Secure Erase
Special Memory O.C. Design
- Superb memory O.C. capability under full load by minimizing the coupling
noise and signal reection effect
<Connectivity>
32Gb/s M.2 onboard - PCIe 3.0 x4
Intel
®
Thunderbolt 3 Support
- Blistering-fast 40Gb/s data transfers upgrades with ThunderboltEX 3 Card.
<EZ Management>
File Transfer
- Cloud GO!
- File Transfer
PC Cleaner
- Fast and easy way to get rid of unnecessary junk les
