Asus ROG STRIX X370-F GAMING [15/78] Chapter 1

ASUS ROG STRIX X370-F GAMING

1-3

Chapter 1

Layout contents

Connectors/Jumpers/Buttons and switches/Slots Page

1. ATXpowerconnectors(24-pinEATXPWR;8-pinEATX12V) 1-16

2. CPU,CPUoptional,waterpump+,AIOpump,andchassisfanconnectors

(4-pinCPU_FAN;4-pinCPU_OPT;4-pinW_PUMP+;4-pinAIO_PUMP;

4-pinCHA_FAN1-3)

1-15

3. AM4CPUsocket 1-4

4. RGBheaders(4-pinRGB_HEADER1-2) 1-17

5. DDR4DIMMslots 1-4

6. QLEDs(BOOT,VGA,DRAM,CPU) 1-8

7. USB3.1frontpanelconnector(USB3.1_C1) 1-12

8. M.2Socket3 1-18

9. AMDSerialATA6.0Gb/sconnectors(7-pinSATA6G_1-8) 1-11

10. StandbypowerLED(SB_PWR) 1-8

11. 3DMountholes 2-11

12. Systempanelconnectors(20-5pinPANEL) 1-14

13. USB3.0connectors(20-1pinUSB3_78,USB3_910) 1-12

14. ClearRTCRAMjumper(2-pinCLRTC) 1-9

15. USB2.0connector(10-1pinUSB34) 1-13

16. Thermalsensorconnector(2-pinT_SENSOR)

1-13

17. TPMconnector(14-1pinTPM) 1-10

18. Frontpanelaudioconnector(10-1pinAAFP) 1-10
