ix
(continued on the next page)
USB
AMD Ryzen / 7th Generation A-series / Athlon™ Processors
- 4 x USB 3.0 ports (4 ports at back panel[blue])
AMD X370 chipset
- 1 x USB 3.1 front panel connector
- 6 x USB 3.0 ports (2 ports at back panel[blue], 4 ports at mid-
board)
- 4 x USB 2.0 ports (2 ports at back panel, 2 ports at mid-board)
ASMedia
®
USB 3.1 controller
- 2 x USB 3.1 ports (2 ports at back panel, Type-A and Type-C)
Audio
SupremeFX S1220A 8-Channel high-denition CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120 dB SNR stereo playback output and 113 dB SNR
recording input
- SupremeFX Shielding Technology
- Dual Headpone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Feature
- Sonic Studio III
- Sonic Radar III
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio.
ROG Exclusive Features
ROG RAMCache II
ROG GameFirst IV*
ROG Overwolf
ROG CPU-Z
ROG CloneDrive
* ROG GameFirst IV is only available for Windows
®
10 64-bit.
Special Features
Performance Optimization
5-Way Optimization
- Whole system optimization with a single click! Perfectly
consolidates better CPU performance, power saving, digital
power control, system cooling and app usages.
Digi+VRM
EPU
- EPU
TPU
- Auto Tuning, TurboV, GPU Boost
Fan Xpert 4
- featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
ROG STRIX X370-F GAMING specications summary
