viii
ROG STRIX X370-F GAMING specications summary
(continued on the next page)
CPU
AM4 socket for AMD Ryzen / 7th Generation A-series /
Athlon™ Processors
Supports AM4 socket 14nm CPU
Chipset
AMD X370
Memory
AMD Ryzen Processors
- 4 x DIMM, max. 64GB, DDR4 3200 (O.C.) / 2666 / 2400 / 2133
MHz, non-ECC, un-buffered memory*
AMD 7th Gen A-series/Athlon™ Processors
- 4 x DIMM, max. 64GB, DDR4 2400 / 2133 MHz, non-ECC, un-
buffered memory*
Dual channel memory architecture
* Please refer to Memory QVL (Qualied Vendors List) for details.
Expansion slots
AMD Ryzen Processors
- 2 x PCIe 3.0 x16 (supports x16, x8/x8)
AMD 7th Generation A-series/Athlon™ Processors
- 1 x PCIe 3.0 x16 (supports x8)
AMD X370 chipset
- 1 x PCIe 2.0 x16 (max. at x4 mode)*
- 3 x PCIe 2.0 x1
* PCIeX16_3 slot shares bandwidth with PCIeX1_2 and PCIeX1_3.
Graphics
Integrated AMD Radeon™ R Series Graphics in the 7th Generation
A-series APU
Multi-VGA output support: HDMI and DisplayPort ports
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160
@24Hz / 2560 x 1600 @60Hz
- Supports DisplayPort 1.2 with maximum resolution of 4096 x 2160
@60Hz
- Maximum shared memory of 2048 MB
Multi-GPU support
Supports NVIDIA
®
2-Way SLI™ Technology
Supports AMD 3-Way CrossFireX Technology
Storage
AMD Ryzen Processors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 (PCIE
3.0 x4 and SATA modes) storage devices support
AMD 7th Generation A-series / Athlon™ Processors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 (SATA
mode) storage devices support
AMD X370 chipset with RAID 0, 1, 10 support
- 8 x SATA 6Gb/s ports
LAN
Intel
®
Ethernet Controller I211-AT
Anti-surge LANGuard
ROG GameFirst IV
