xi
STRIX B250I GAMING specications summary
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, SM BIOS 3.0, ACPI
5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ
Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log, F12
PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence
Detect) memory information.
Manageability
DMI3.0, WOL by PME, PXE
Support DVD
contents
Drivers
ASUS Utilities
ASUS EZ Update
Anti-virus software (OEM version)
Operating
system support
Windows
®
10 64-bit
Windows
®
8.1 64-bit*
Windows
®
7*
* Windows
®
8.1 64-bit and Windows
®
7 32/64-bit are only supported when using
6th Generation Intel
®
Processors.
Form factor
Mini ITX Form Factor, 6.7” x 6.7” (17cm x 17cm)
Specications are subject to change without notice. Please refer to the ASUS website for
the latest specications.
