Asus ROG STRIX B250I GAMING [12/78] Package contents

xii

Package contents

Check your motherboard package for the following items.

Motherboard STRIX B250I GAMING

Cables

2 x SATA 6Gb/s cables

1 x RGB LED extension cable (80cm)

1 x Panel Cable

Accessories

1 x ASUS 2x2 dual band Wi-Fi moving antennas

2 x M.2 2242 Mounting Kits

1 x I/O shield

1 x ROG Strix sticker

1 x 10-in-1 ROG cable label

2 M.2 screw packages

1 x Cable tie

Application drive ROG motherboard support DVD

Documentation User Guide

If any of the above items is damaged or missing, contact your retailer.
