ix
(continued on the next page)
STRIX B250I GAMING specications summary
Storage
Intel
®
B250 Chipset and Intel
®
Rapid Storage Technology 15 support
- 4 x SATA 6Gb/s ports
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 4 modes)*
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280 storage devices
support (PCIE 3.0 x 4 mode)*, supports Intel
®
Rapid Storage Technology
and Intel
®
Optane
TM
Memory**
* For a 2242 storage device, use the bundled 2242 mounting kit.
** Intel
®
Optane
TM
Technology is only supported when using 7th Generation Intel
®
Processors. Before using Intel
®
Optane
TM
memory modules, ensure that you have
updated your motherboard drivers and BIOS to the latest version from ASUS
support website.
Audio
ROG SupremeFX S1220A 8-Channel High Denition Audio CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR recording
input
- SupremeFX Shielding Technology
- Dual Headpone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features
- Sonic Radar III
- Sonic Studio III
* Due to limitations in HDA bandwidth, 32-bit/192kHz is not supported for
8-Channel audio and due to Windows
®
7 limitations, 32-bit playback is
unavailable for Windows
®
7.
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst IV*
* ROG GameFirst Technology is only available for Windows 10/8.1 64-bit.
ROG Exclusive
Features
ROG Aura
- Aura effects
- 1 x Aura RGB headers
ROG RAMCache II
ROG GameFirst IV
ROG Overwolf
ROG Clone Drive
ROG CPU-Z
