Asus ROG STRIX B250I GAMING [19/78] Recommended memory configurations

ASUS STRIX B250I GAMING

1-5

Chapter 1

Recommended memory congurations

1.1.4 System memory

The motherboard comes with two DDR4 (Double Data Rate 4) Dual Inline Memory Modules

(DIMM) slots.

A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT

install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.

STRIX B250I GAMING 288-pin DDR4 DIMM sockets

DIMM_A1

DIMM_B1
