xii
STRIX Z270H GAMING specifications summary
Internal I/O
connectors
2 x USB 3.0 connector supports additional 4 x USB 3.0 ports
2 x USB 2.0 connectors support additional 4 x USB 2.0 ports
6 x SATA 6Gb/s connectors
1 x 4-Pin CPU_FAN connector
1 x 4-Pin CPU_OPT fan connector
1 x 4-Pin AIO_PUMP connector
2 x 4-Pin CHA_FAN connectors
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280/22110 storage devices
support (both SATA & PCIE 3.0 x 4 mode)
1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280 storage devices support
(PCIE 3.0 x 4 mode)
1 x Front panel audio connector (AAFP)
1 x COM connector
1 x TPM connector
1 x Clear CMOS jumper
1 x System panel connector
1 x CPU_OV jumper
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI
6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ
Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log, F12
PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory
information.
Manageability
WfM2.0, DMI3.0, WOL by PME, PXE
Support DVD
contents
Drivers
ROG Game First IV*
ROG RAMCache II
ROG Clone Drive
ROG CPU-Z
Anti-virus software (OEM version)
ASUS WebStorage
ASUS Utilities
* ROG GameFirst IV is only available for Windows
®
10/8.1 64-bit.
Operating
system support
Windows
®
10 64-bit
Windows
®
8.1 64-bit*
Windows
®
7*
* Windows
®
8.1 64-bit and Windows
®
7 32/64-bit are only supported when using
6th Generation Intel
®
Processors.
Form factor
ATX Form Factor, 12”x 9.2” (30.5cm x 23.4cm)
Specications are subject to change without notice. Please refer to the ASUS website for
the latest specications.
