ROG STRIX Z270H GAMING
1-19
Chapter 1
11. M.2sockets(M.2_1;M.2_2)
ThesesocketsallowyoutoinstallM.2SSDmodules.
• M.2_1socketsupportsPCIe3.0x4andSATAmodeMKeydesignandtype2242/
2260/2280/22110PCIeandSATAstoragedevices.
• M.2_2socketsupportsPCIe3.0x4MKeydesignandtype2242/2260/2280PCIe
storagedevices.
• ThesesocketssupportIRST(Intel
®
RapidStorageTechnology).
TheM.2SSDmoduleispurchasedseparately.
