Ryobi eid1050rs [6/86] English
![Ryobi eid1050rs [6/86] English](/views2/1237029/page6/bg6.png)
2
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
OPERATION
IMPACT DRILLING MODE: Shift the knob to the " "
and showing "
" symbol for impact drilling.
OPERATING
NEVER COVER THE AIR VENTS (10) SINCE THEY
MUST ALWAYS BE OPEN FOR PROPER MOTOR
COOLING.
DRILLING IN WOOD
To prevent ugly splits around the drill hole on the reverse
side of the workpiece, put a piece of scrap timber under
the work piece.
DRILLING IN METAL
Metals such as steel, brass, aluminum sheets, stainless
steel, and pipe may also be drilled. Mark the point to be
drilled with a nail or punch.
Do not use impact drilling mode on these materials.
DRILLING IN CONCRETE
Stone and masonry are generally drilled in the impact
drilling mode.
When drilling in delicate materials such as wall tiles,
it is essential to start with ordinary drilling and, once the
tile is pierced, to continue with impact drilling.
In deep bore holes the drill bit should be pulled out
occasionally in order to remove the debris from the
drill and hole.
AUXILIARY HANDLE AND DEPTH GAUGE
See Figure 6.
Auxiliary handle
The auxiliary handle (8) can be rotated 360º.
Loosen the handle grip by turning in direction (15),
and tighten it at an easy to use position by turning
the grip in direction (14).
Depth gauge
Holes of a fixed depth can be accurately bored by using
the depth gauge (7).
The depth of the hole will be the distance from the end
of the bit to the end of the depth gauge.
By turning the handle grip in direction (14), the depth
gauge can be released and the depth adjusted. After
adjusting the depth, fix the depth gauge again by turning
the handle grip in direction (15).
BIT STORAGE
See Figure 7.
The auxiliary handle also contains a compartment to
store drill bits. To access this compartment unscrew
the end cap below the grey trim on the handle in an
anticlockwise direction.
SPINDLE LOCK
See Figure 8.
For easy changing of the drill bit this drill is equipped with
an automatic spindle lock (17) which holds the spindle
stationary when loosening and tightening the chuck.
BUBBLE LEVEL
See Figure 1.
A bubble vial is located on the top of the motor housing
to help keep the drill bit level during use. This ensures
maximum accuracy in drilling.
LIVETOOL INDICATOR™
This tool features a Livetool Indicator™ (11) which
illuminates as soon as the tool is connected to the power
supply. This warns the user that the tool is connected and
will operate when the switch is pressed.
MAINTENANCE
After use, check the tool to make sure that it is in good
condition. It is recommended that you take this tool to
a RYOBI Authorized Service Center for a thorough
cleaning and lubrication at least once a year.
DO NOT MAKE ANY ADJUSTMENTS WHILE
THE MOTOR IS IN MOTION. ALWAYS DISCONNECT
THE POWER CORD FROM THE POWER SUPPLY
BEFORE CHANGING REMOVABLE OR CONSUMABLE
PARTS (BLADE, BIT, ETC.), LUBRICATING OR
WORKING ON THE UNIT.
WARNING
To ensure safety and reliability, all repairs should
be performed by an AUTHORIZED SERVICE
CENTER or other QUALIFIED SERVICE
ORGANIZATION.
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
