ENGLISH

(Original instructions)

Caution! Allow the tool to reach full speed before

touching tool to the work surface. Lift the tool from

the work surface before turning the tool off.

Spindle lock

The spindle lock button (5) is provided to prevent the spindle

from rotating when installing or removing wheels. Operate

the spindle lock only when the tool is turned off and the

wheel has come to a complete stop.

Warning! Do not engage the spindle lock while the tool is

operating. Damage to the tool will result and attached

accessory may spin off possibly resulting in injury.

To engage the lock, depress the spindle lock button shown

in Fig. E and rotate the spindle until you are unable to rotate

the spindle further.

Mounting And Using Depressed Center

Grinding Wheels And Sanding Flap Discs

Mounting and Removing Hubbed Wheels

Warning! To prevent accidental operation, turn

off and unplug tool before performing the

following operations. Failure to do this could

result in serious personal injury.

Hubbed wheels install directly on the 5/8 in.-11 threaded

spindle.

1. Thread the wheel on the spindle by hand.

2. Depress the spindle lock button and use a wrench

(Fig. E) to tighten the hub of the wheel.

3. Reverse the above procedure to remove the wheel.

Caution! Failure to properly seat the wheel before

turning the tool on may result in damage to the tool

or the wheel.

Mounting Non-Hubbed wheels

Warning! To prevent accidental operation, turn off

and unplug tool before performing the following

operations. Failure to do this could result in serious

personal injury.

1. Figure F: Install the unthreaded backing ﬂange (10) on

spindle (11) with the raised section (pilot) against the

wheel.

2. Place wheel against the backing ﬂange, centering the

wheel on the raised section (pilot) of the backing ﬂange.

3. Figure G: While depressing the spindle lock button,

thread the threaded clamp nut (12) on spindle.

► Figure H: If the wheel you are installing is more than 1/8

inch (3mm) thick, place the threaded clamp nut on the

spindle so that the raised section (pilot) ﬁts into the

center of the wheel.

► Figure I: If the wheel you are installing is 1/8 inch (3mm)

thick or less, place the threaded clamp nut on the spindle

so that the raised section (pilot) is not against the wheel.

4. While depressing the spindle lock button (5), tighten the

threaded clamp nut with included wrench.

5. To remove the wheel, depress the spindle lock button

and loosen the threaded clamp nut with included wrench.

Note: If the wheel spins after the threaded clamp nut is

tightened, check the orientation of the threaded clamp nut. If

a thin wheel is installed with the pilot on the clamp nut

against the wheel, it will spin because the height of the

pilotprevents the clamp nut from holding the wheel.

Surface grinding with grinding wheels

1. Allow the tool to reach full speed before touching the tool

to the work surface.

2. Apply minimum pressure to the work surface, allowing

the tool to operate at high speed. Grinding rate is

greatest when the tool operates at high speed.

3. Figure J: Maintain a 20˚ to 30˚ angle between the tool

and work surface.

4. Continuously move the tool in a forward and back motion

to avoid creating gouges in the work surface.

5. Remove the tool from work surface before turning tool

off. Allow the tool to stop rotating before laying it down.

Maintenance

Cleaning

Warning! Blowing dust and grit out of the motor

housing using compressed air is a necessary

maintenance procedure. Dust and grit from metal

grinding often accumulate on interior surfaces and could

create an electrical shock hazard if not cleaned out.
